STANDARD | WERKSTOFF NR. | UNS | AFNOR | GOST | JIS | BS | EN | OR |
Incoloy 330 | 1.4886 | N08330 | - | - | - | - | - | - |
Product name | Incoloy 330 Flanges |
---|---|
Specification | ASTM / ASME SB 564 / 160 / 472 |
Inconel UNS Grade | Inconel 600 (UNS N06600, Alloy 600, 2.4816), Inconel 601 (UNS N06601, Alloy 601, 2.4851), Inconel 625 (UNS N06625, Alloy 625, 2.4856), Inconel 800 (UNS N08800, Alloy 800) |
Flanges Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
Size | ½" to 36" |
Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
GRADE | C | MN | P | S | Si | Cr | Ni | Mo | Cu | Fe | Sn | Pb |
Incoloy 330 | 0.08 max | 2.00 max | 0.03 max | 0.03 max | 0.75-1.50 | 17.0-20.0 | 34.0-37.0 | 1.0-1.75 | 1.00 max | Balance | 0.025 | 0.005 max |
Specification | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
Grade | ASTM B564 Inconel 600 (UNS N06600, Alloy 600, 2.4816), Inconel 601 (UNS N06601, Alloy 601, 2.4851), Inconel 625 (UNS N06625, Alloy 625, 2.4856), Inconel 800 (UNS N08800, Alloy 800) |
Connect Type/ Flange Face Type | Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ), Lap-Joint Face (LJF), Large Male-Female (LMF), Small Male-Female (SMF), Large Tongue & Groove, Small Tongue, Groove |
Surface treatment | Anti-rust oil, transparent/ yellow/ black anti trst paint, Zinc, hot dipped galvanized |
Size Range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
Pressure | DIN:PN6 PN10 PN16 PN25 PN40; ANSI: class: 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-PN6, PN10, PN16, PN25, PN40, PN64 etc. JIS: 5K, 10 K, 16 K 20 K,30 K,40 K, 63 K; |
Standard | ANSI DIN,GOST,JIS,UNI,BS,AS2129,AWWA,EN,SABS,NFE etc. ANSI Flange, ASME Flange, BS Flange, DIN Flange, EN Flange
|
Production technique: |
|
Special design | As per your drawing
AS, ANSI, BS, DIN and JIS ASTM B564 Incoloy 330 Threaded Flange, Slip-On Flange, Socketweld Flange, Weld Neck Flange, Blind Flange |
Test | Direct-reading Spectrograph,Hydrostatic testing machine,X-ray detector,UI trasonic flaw detector,Magnetic particle detector |
Equipment | Press machine ,Bending machine,Pushing Machine,electric bevelling machine Sand-blasting machine,etc |
Origin | West Europe / Japan / Indian / USA / Korean |
Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
Specialized manufacturer of | ASTM B564 Incoloy 330 Blind Flanges, ASTM B564 Incoloy 330 Table Flanges, ASTM B564 Incoloy 330 Weld Neck Flanges, ASTM B564 Incoloy 330 Threaded Flanges, ASTM B564 Incoloy 330 Slip-On Flanges, ASTM B564 Incoloy 330 Socketweld Flanges, ASTM B564 Incoloy 330 Plate Flanges, ASTM B564 Incoloy 330 Lap Joint Flanges, ASTM B564 Incoloy 330 Loose Flanges, and ASTM B564 Incoloy 330 Orifice Flanges. ASTM B564 Incoloy 330 AS 4087 Water Flanges are available in class 150, 300, 600, 900, 1500 and 2500. |
Key markets and industries for ASTM B564 Incoloy 330 Flanges |
|
Reason to choose ASTM B564 Incoloy 330 Pipe Flanges, Key properties |
|
Similar Pipe Fittings Key grades |
|
ASME/ANSI B 16.5 | Welding Neck Flange, Slipon Flange, Blind Flange, High Hub Blind Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Ring Type Joint Flange |
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
ASME/ANSI B 16.47 | Welding Neck Flange, Blind Flange [Series A & B] |
PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
ASME/ANSI B 16.36 | Welding Neck Flange, Slipon Flange, Threaded Flange |
PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
BS 4504 SEC 3.1 | Welding Neck Flange, Hubbed Slipon Flange, Hubbed Threaded Flange, Lapped Pipe End Flange, Plate Flange,Loose Plate Flange, Loose Plate With Weld Neck Flange, Blank Flange |
PRESSURE CLASS | PN 2.5 TO PN 40 |
BS 4504[PART 1] | Welding Neck Flange, Hubbed Slip-On Hubbed Threaded, Plate Flange, Loose Plate With Weld On Plate Collar, Blank Flange |
PRESSURE CLASS | PN 2.5 TO PN 400 |
BS 1560 BOSS | Welding Neck Flange, Socket Welding Flange, Slip-On Flange, Blind Flange,Screwed Boss Flange, Lapped Flange |
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
BS10 | Welding Neck Flange, Plate Slip-On Flange, Screwed Boss Flange, Slip-On Boss Flange, Blind Flange |
TABLE | D, E, F, H |
DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636,2637,2638, 2673 |
PRESSURE CLASS | PN 6 TO PN 100 |
Type
|
Dimension range *
|
Drawing**
|
ASTM B564 Incoloy 330 Blind Flanges
ASTM B564 Incoloy 330 Blind Flanges |
DN15 – DN2500
½ “- 24″ |
DIN2527 PN16 DN150 BL 300lb 6 “
|
ASTM B564 Incoloy 330 Threaded with neck
ASTM B564 Incoloy 330 Threaded Flanges |
DN15 – DN150
½ “- 24″ |
DIN2566 DN32 / 42.4 TH 300lb 1 “
|
Flanges smooth for welding
|
DN15 – DN2500
|
DIN2576 DN150
|
ASTM B564 Incoloy 330 Welding neck
ASTM B564 Incoloy 330 Welding Neck Flanges |
DN15 – DN2500
½ “- 24″ Dy10 – Dy2400 |
DIN2635 DN150 / 168.3 WN 300lb 6 “GOST Dy150 Py16
|
ASTM B564 Incoloy 330 loose flanges, smooth Bunde
|
DN15 – DN2500
|
DIN2642 DN150
|
ASTM B564 Incoloy 330 loose flanges Stub
|
DN15 – DN2500
|
DIN2673 DN150
|
ASTM B564 Incoloy 330 Welding flanges with neck
ASTM B564 Incoloy 330 Slip On Flanges |
DN15 – DN2500
½ “- 24″ Dy10 – Dy2400 |
DIN86030 DN150
SO 300lb 6 ” GOST |
ASTM B564 Incoloy 330 Lap Joint Flanges
|
½ “- 24″
|
LJ 300lb 6 “
|
ASTM B564 Incoloy 330 Socket Welding Flanges
|
½ “- 3″
|
SW 300lb 6 “
|
Ranflex Metals is one of the Leading Manufacturer, Supplier and Exporter Of Incoloy 330 Flanges is a nonmagnetic nickel-chromium alloy with properties that include high temperature strength comparable to 18-8 alloys and high resistance to organic and inorganic corrosives.India's Most Experienced Manufacturers, Suppliers and Exporter of Incoloy 330 Flanges, Incoloy 330 Weld neck Flanges, Incoloy 330 Slip on Flanges, Incoloy 330 Socket weld Flanges, Incoloy 330 Blind Flanges, Incoloy 330 Lapped joint Flanges, Incoloy 330 Threaded Flange, Incoloy 330 Plate Flange in India & UK,We are largest Manufacturers of Incoloy 330 Flanges manufacturer, Incoloy 330 Slip On Flange, Incoloy 330 Welding Neck Flange, Incoloy 330 Blind Flange, Incoloy 330 Socket Weld Flanges, Incoloy 330 Plate Flange, Incoloy 330 Collar Flange, Incoloy 330 Threaded Flange Manufacturers in India. ANSI/ASME B16.5,B16.47,B16.47,B16.36, B16.48 Incoloy 330 Flanges,Best Price Of Incoloy 330 Flanges manufacturer, alloy 330 flanges, inconel alloy 330 flanges, ASTM b564 Incoloy 330 Flanges, Incoloy 330 Flanges suppliers, Seamless/Seam Welded Incoloy 330 Flanges, Fabricated Incoloy 330 Flanges, Incoloy 330 Flanges Exporters in India.
Erne Fittings, Austria | Metal far, Italy | Lame S.R.l., Italy |
BENKAN Corporation, Japan | BKL- Thai Benkan, Thailand | TecnoForge, Italy |
Ulma, Spain | Mega, Italy | Melesi, Italy |
Interfit, France | Raccortubi S.P.A., Italy |
Scope* :-
This specification2 covers forgings of nickel alloy UNS N02200, Ni-Cu alloy UNS N04400, Ni-Cr-Fe alloys UNS N06600, UNS N06603, and UNS N06690, Ni-Cr-Mo-Nb alloy UNS N06625, Ni-Cr-Mo-Si alloy UNS N06219, low-carbon Ni-Mo-Cr alloys UNS N10276 and UNS N06022, Ni-Cr-Mo-W alloy UNS N06110, low-carbon Ni-Cr-Mo-W alloy UNS N06686, Ni-Fe-Cr-Mo-Cu alloy UNS N08825, Fe-Ni- Cr- Mo-N alloy UNS N08367, low-carbon Ni-Cr-Mo alloys UNS N06035, UNS N06058, and UNS N06059, low carbon Ni-Cr- Mo-Cu alloy UNS N06200, Ni-Mo-Cr-Fe alloy UNS N10242, Ni-Mo alloys UNS N10665 and UNS N10675, low-carbon Ni-Fe-Cr-Mo-Cu alloy UNS N08031, Ni-Cr-W-Mo alloy UNS N06230, Ni-Cr-Co-Mo alloy UNS N06617, Ni-Co-Cr-Si alloy UNS N12160, Ni-Fe-Cr alloys, Ni-Mo alloy UNS N10629, Ni-Cr-Fe-Al alloy UNS N06025, Ni-Cr-Fe-Si alloy UNS N06045, Low-Carbon Ni-Mo- Cr-Ta alloy UNS N06210, Ni- Mo-Cr-Fe alloy UNS N10624, and low-carbon Cr-Ni-Fe-N alloy UNS R20033*
The nickel-iron-chromium alloys are UNS N08120, UNS N08800, UNS N08810, and UNS N08811. Alloy UNS N08800 is normally employed in service temperatures up to and including 1100°F (593°C). Alloys UNS N08810, N08120, and UNS N08811 are normally employed in service tempera tures above 1100°F where resistance to creep and rupture is required, and are annealed to develop controlled grain size for optimum properties in this temperature range.
The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to become familiar with all hazards including those identified in the appropriate Material Safety Data Sheet (MSDS) for this product/material as provided by the manufacturer, to establish appropriate safety and health practices, and determine the applicability of regulatory limitations prior to use.
